5723-8203 - 2-Port Asynchronous EIA-232 PCI Adapter

Connection for 2 Asynchronous EIA-232 devices. Ports are Programmable to support EIA-232 protocols, at a line speed of 128K bps.

Attributes provided: 2 Asynchronous Ports

Attributes required: One PCI Slot

For 8203-E4A: The IBM Power6 8203-E4A (#5723)

Minimum required: 0

Maximum allowed: 18 (Initial order maximum: 18)

OS Level required: AIX 5.3 with the 5300-07 Technology Level or later. AIX 6.1 or later. SUSE Linux Enterprise server 10 SP1 for POWER systems, or later. Red Hat Enterprise Linux for POWER, version 4.5, or later. Red Hat Enterprise Linux for POWER, version 5.1, or later.

Initial Order/MES/Both/Supported: Both

CSU: Yes

Return parts MES: No

Note: Maximum of two allowed in CEC under AIX or Linux.

System maximum of 18 under AIX or Linux. Not supported under IBM i.
